Manufacturer: Telegärtner

Whether in classic building cabling in office buildings, in data centers, in industry or for home cabling:
The field-assembly MFP8 is the first choice wherever powerful and reliable connections are required without great effort. And of course it is suitable for High Power over Ethernet (PoE+).

The MFP8-SL RJ45 connector is characterized by a very short installation length of just 44 mm. The finely graduated cable clamp accommodates cables with an outer diameter of up to 9 mm. Barbs in the cable fixing increase the strain relief. The pre-assembled protective cap provides effective protection for the contacts against dirt and transport damage, even during cable assembly.

The standardized mating face in accordance with EN 60603-7-51, the robust die-cast zinc housing with a tempered surface to protect against external electrical interference and 360° shielding for reliable data transmission even in the event of electrical interference make this connector flexible to use.

The IPC piercing contacts are suitable for conductor cross-sections AWG 27/7 - 22/7; AWG 26/1 - 22/1; AWG 26/19 - 24/19. The 4-chamber wire management is available with color coding according to T568A, T568B and PROFINET.

   Further technical information is available in our online shop!

Telegärtner SMA connectors represent the top class in connection technology.

They offer outstanding performance and reliability in the world of high frequency technology.

Whether in telecommunications or measurement technology - our SMA connectors meet the
highest quality standards and guarantee interference-free communication.

With a compact design and effortless handling, they are the ideal choice.
The 50 ohm wave impedance and the frequency bandwidth of up to 18 GHz,
depending on the version, make them particularly versatile.

Our range not only includes cable connectors for flexible, semi-flex and semi-rigid cables,
but also PCB connectors.

You will also find a wide selection of adapters between different coax series in our online shop.

    Rely on Telegärtner to take your connections to the next level and achieve maximum flexibility!

With the MFP8 series, Telegärtner Karl Gärtner GmbH provides a field-assembly RJ45 connector solution for structured network cabling.

Whether a cable route needs to be repaired, replaced or extended the flexible connectors enable time-saving assembly without great effort on site.

It doesn't matter whether it's an installing of simple infrastructures in the home network or operating high-speed networks of up to 40 gigabits in data centers. The connectors have sufficient power reserves for every application.

The RJ45 connectors with full-metal housing and 4-stage cable catch can be installed in just 60 seconds without special tools and are available in straight and angled versions.

Depending on the type, they fulfill Cat.6(deep)A as well as the requirements of Cat.8.1.

Processing with flexible conductors from 27/7AWG to 22/7AWG and rigid wires from 26/1AWG to 22/1AWG is possible without any problems.

For more information and an overview of the available versions, please visit our online store.

For several years now, the media landscape has been discussing the new digital video format 4k/8k or UHD (Ultra HD), which is intended to replace the currently widespread Full HD.
With four times the resolution and frequency, the new format is supposed to offer a razor-sharp image as well as greater color depth.

The big challenge on the technical side is to adapt the infrastructure to the transmission of high data volumes and over long distances.

Telegärtner's UHD-BNC connector was specially developed for 4k/8k applications with UHD cables from leading manufacturers. Thanks to the design optimized for high frequencies, particularly good return loss values of min. -22dB @12 GHz could be achieved.

The connector is capable of transmitting higher data rates of up to 24 Gb/s at 12 GHz. Thanks to the excellent electrical transmission properties, cable lengths of over 100 m are possible.

An overview of the available versions as well as further technical data is available in our online store.

Where connectivity takes place, where data and signals are transmitted and connections are made, Telegärtner creates solutions.

Connectors are the core competence: With a production of several million units and 11 locations worldwide, Telegärtner Karl Gärtner GmbH is always your first partner.

In this EVE PAGER we offer you a wide range of coaxial connectors of the BNC series.
At a glance you will find all important technical details and direct links lead to our online store with current prices, availabilities and ordering options.

The BNC series includes the most commonly used coaxial connectors, which are used up to a frequency of 4 GHz. They feature a bayonet lock and are offered in 50 Ω and 75 Ω characteristic impedance versions.

Cable connectors are available for flexible, semi-flex and semi-rigid cables. PCB connectors and receptacles are also available. The connectors of the BNC series meet the transverse tightness in the mating face between plug and socket in mated condition all-inclusive according to IP 54.

PS: Check the availability of our Telegärtner articles via our webshop! A large part of the articles is available for you directly or within a few working days!

As an owner-managed family business, the Telegärtner Group has developed over the past 70 years into a globally active specialist in data and telecommunications. With comprehensive solutions, which are used in many companies worldwide, Telegärtner as a trend-setting expert.

From the range of coaxial components, Telegärtner offers a wide selection of adapters between the series. Almost all common combinations of BNC, TNC, N, UHF, FME, SMA, MCX, 4.3-10, or 7-16 connectors are available.

Depending on the connector, couplers with a male and female connector, as flush-mounted or flanged versions can be ordered.

Telegärtner attaches great importance to excellent RF characteristics with corresponding attenuation values. Both common requirements for the maximum possible transmission frequency as well as requests for high IP standards can be fulfilled in different connector combinations.

Expert tip:
Use the adapters as so-called Connector Saver to protect the test port of high-quality measuring instruments. The Telegärtner Connector Saver are screwed onto the original port, which therefore does not wear out even with frequent use. The Connector Saver can be can be replaced quickly and cost-effectively.

You can find these and other Telegärtner products in our webshop.

The RF connectors in the series SIMFix® are rugged connectors with threaded coupling for use in high performance transmitter applications. These connectors are waterproof and are suitable for external use. Furthermore, they are designed to provide excellent technical performance, especially concerning return loss and intermodulation.

The SIMFix® range includes RF connectors for terminating 1/4“, 1/2” flex, 1/2”, 7/8”, 1 1/2” and 1 5/8” sized corrugated cables.

Assembly for all sizes is simple and reliable, thus guaranteeing constantly good electrical performance with regard to return loss and intermodulation. Ease of termination of the cables has been greatly enhanced by the use of specially developed tooling, which allows for exact stripping of the corrugated cables in the shortest of time.

With SIMFix® Pro a waterproof version with IP68 certification is also available.

Connectors with SIMFix® coupling can be found with the series 2.2-5 and 4.3-10.

You can also find other Telegärtner products in our Internet shop.

The Best in Class: 5G Connectors made by Telegärtner

Ever-increasing amounts of data have made further developments of global mobile networks essential. Above all, the development of 5G – the next generation of mobile communications – is creating new and more diverse tasks for the mobile communications industry.

Highest RF-Power in Class

The 2.2-5 series has adopted the successful concept of 4.3-10 and reduced the size accordingly. While the 4.3-10 typically require the same installation space as the classic N-connector, the 2.2-5 are satisfied with the standard installation dimensions of the TNC series.

The 2.2-5 series enables a robust and PIM stable design in the smallest space. The space requirements for a typical 4 hole flange jack are only 17.4 x 17.4 mm. Therefore the 2.2-5 requires around 53 % less space  than  the  4.3-10  series  and  70  %  less  space than the 7-16 series.

Hand in hand with the size and material reduction, there is also a cost and weight reduction, meaning this series is ideal for small cell applications. Despite the small  size,  relatively  thick  and  therefore  low  loss cables up to ½” can be used both indoors and outdoors.

Advantages

• space and weight savings due to compact design
• optimized for 1/4", 3/8" and 1/2" corrugated cables
• very low PIM values independent form torque and coupling mechanism
• contact areas protected from damage even when not mated
• Screw, Handscrew and Push Pull options with same jack

Detailed information on this new connector series can be found in Telegärtner's PDF brochure.

The range of cable connectors, sockets, couplings and adapters can also be ordered directly from our online shop.

Your customer advisor will also be pleased to answer any questions you may have.

Telegärtner has optimised and redesigned its AMJ-S Module especially for very demanding applications that have to guarantee high reliability in extremely tough environments.

The reworked Module features outstanding robustness against mechanical and electrical influences. In addition, its transmission characteristics exceed those laid down by the corresponding standard and it thus provides a significantly higher transmission reserve. This is verified several times a year by GHMT, an independent testing laboratory, as part of the Premium Verification Program.

It offers even higher headroom and is approved for use with Four Pair Power over Ethernet with currents of up to 1,000 milliamperes.

Like its predecessor, the new AMJ-S Module 2G can be easily connected without special tools. It also has the same dimensions and therefore fits into all patch panels, outlets and module carriers in the Telegärtner AMJ series.

The new AMJ-S Modules 2G can be ordered directly from our online shop.

J00029A3000 AMJ-S Module 2G Cat.6A T568A
J00029A3001 AMJ-S Module 2G Cat.6A T568B

Further comprehensive information on all AMJ-S modules can be found in the Telegärtner PDF brochure.

All listed products can be delivered from Telegärtner's warehouse within 24 hours.
