Manufacturer: Telegärtner

DataVoice Industry
Reliable Connectors for Industrial Ethernet

Whether for factory or machinery and equipment wiring, the Telegärtner Variant 1, Variant 4 and Variant 5 lines of industrial plug-in connectors offer standards-compliant solutions which can be flexibly combined with one another without the need for cumbersome adapters. The freely selectable inserts can be used in conjunction with all IP67 protective housings. Nothing is simpler and simultaneously more reliable for today’s gigabit-speed plant, machinery and equipment networks

Components for the Control Cabinet / STX Mounting Rail Outlets by Telegärtner

The STX Mounting Rail Outlets utilizing STEADYTEC® technology are available in a wide variety of applications (RJ45, USB coupler, fiber optic adaptors). The use of freely selectable modules which can be easily inserted into the housings provides a high level of flexibility in both component selection as well as in areas of application.

The Variants designed for fully-screened RJ45 jacks Cat.6A and RJ45 Couplers Cat.6 Class EA are equipped with a functional earth which can be switched on/off during operation. This simplifies fault analyses in the grounding concept while also separating the potentials between the network and the control cabinet.

Components for Field Cabling / Variant 1 by Telegärtner

Connectors for modern industrial applications need to be designed in such a way that they simplify processes and cope with faster data transmission. Telegärtner recommends the connectors of Variant 1 for generic cabling of factory automation machinery (Automation Island, ODVA) acc. to IEC 61918 in a robust metal or plastic design.

The connectors of Variant 1 are standardized in the IEC 61076-3-106, designed to meet the demands of harsh industrial environments, guaranteeing protection class IP67 whether mated or unmated (using the IP67 protection cap). Furthermore, the modular principle - which is used on all connectors with STEADYTEC®- Technology allows us to offer a wide range of products. Benefit from maximum flexibility and choose the insert you need! The RJ45 plug and bulkhead inserts stand out due to high power reserves and offer transmission characteristics of ClassEA acc. to ISO/IEC 11801. The FO plug and bulkhead inserts are available for GOF and POF-fibres and provide the most suitablesolution for every application.

Components for Field Cabling / Variant 4 by Telegärtner

The standard for generic cabling in industrial premises ISO/IEC 24702 resp. EN 50173-1 and -3 stipulates the connector of Variant 4.

This extraordinary space saving connector provides a 10 Gbit-link to the machine while having the same installation dimensions as a 4-way M12 connector. The connectors of Variant 4 are standardized in the IEC 61076-3-106, designed to meet the demands of harsh industrial environments, guaranteeing protection class IP67 whether mated or unmated (using the IP67 protection cap).

Components for Field Cabling / Variant 5 by Telegärtner

The Connectors of Variant 5 (Heavy Duty Connector), mostly common from the railway supply industry, wind power and mechanical engineering feature a secure and easy locking using a bail.The connectors of Variant 5 are standardized in the IEC 61076-3-106, designed to meet the demands of harsh industrial environments, guaranteeing protection class IP67 whether mated or unmated (using the IP67 protection cap).

Components for Field Cabling / Variant 6 by Telegärtner

Connectors for modern industrial applications need to be designed in such a way that they simplify processes and cope with faster data transmission. Telegärtner recommends the connectors of Variant 6 for genericcabling of factory automation machinery (Automation Island, ODVA) acc. IEC 61918 and fieldbus installation acc. to IEC 61784-5 in a robust plastic design.

The connectors of Variant 6 are standardized in the IEC 61076-3-106, designed to meet the demands of harsh industrial environments, guaranteeing protection class IP67 when mated. The locking clasps allow easy, tool-less opening as well as a secure locking with protection class IP67. The RJ45 plug and bulkhead inserts stand out due to high power reserves and offer transmission characteristics of Class EA acc. to ISO/IEC1180.

Components for Field Cabling / Variant 14 by Telegärtner

For the installation of data networks as per IEC 61918, IEC 61784-5 and PROFINET system guide, Telegärtner recommends for harsh environments the Push-Pull connector of Variant 14 acc. to IEC 61076-3-117. Moreover this connector series is compliant to the requirements of AIDA (Automation Initiative of the German Automotive Industry) guaranteeing protection class IP67.

Components for Field Cabling / RJ45 Connectors IP20 by Telegärtner

The RJ45 connectors acc. to ISO/IEC 60603-7-5 are available in two designs. The 8-way Cat.6 connector for stranded wire cables AWG22-26 or solid wire cables AWG22-26 can easily be assembled on-site without any special tools. The maximum cable diameter is 8.5 mm. The connector features the EIA/TIA A, B and Profinet coding and a 360° shielding connection. The small and robust zinc diecast housing can also ge supplemented with a colour coding. The 8-way Cat.6 connector for stranded wire cables AWG24-27 and solid wire cables AWG24-27 completes the product line. Assembled with a crimp tool it offers shield connection and a wire presorting for easy handling, too. The strain relief pressure is thereby absorbed by the cable jacket. This avoids deformation of wires. Retrofit, 2-part cable boots in different colours are available additionally. Both connectors are capable for use in patch panels, switches, etc. Suitable crimp tools for professional application round-off the product range.
