Manufacturer: Standex-Meder Electronics

With the MK31 from Standex Meder Electronics you will find one of the smallest reed sensors for SMD assembly in our range. The sensor with normally open contact (SPST-N.O.) is ideally suited for on/off switching or for use in applications with proximity, motion or position detection.

Tape & Reel packaging in accordance with IEC 286/part 3 ensures smooth processing in the assembly process. The UL approval also makes the component interesting for international projects.

Detailed information about this sensor and other products from Standex Meder Electronics can be found in our onlineshop.

The SHV Reed Relay Series is an improved version of the SIL-HV Reed Relay, which is smaller and more compact. An internal magnetic shield provides high shielding for densely packed matrix arrangements.

With a high breakdown voltage and a contact resistance of 70 mOhm, the new SHV relay is ideal for high-voltage applications in the field of test and measurement technology. Further improvements include a higher rated power of 100 W, a switching voltage of 1000 VDC, a switching current of 1 A and an insulation and breakdown voltage of up to 4 kVDC. The insulation resistance between coil and contact is 10 TOhm, and there is also an optional protective diode.

The overmolding has made the relay significantly more resistant to the manufacturing process and everyday use, especially against moisture. Improved resistance is particularly important when using environmentally friendly cleaning agents after the soldering process.

The new SHV relays are RoHS-compliant and are currently in the process of UL certification.

Further information is available in our online store.
