In addition to the extensive product range of DIN 41651 connectors, econ connect, as a specialist for electronic connections, offers a complete range of suitable flat ribbon cables with a cross-section of 28 AWG. The cables are manufactured in accordance with UL 2651 and are available in 1.0 mm and 1.27 mm pitches.

The handy 30.5 m (100 ft) reels are the first choice for your sample production or for the production of small series.

The 76.2 m (250 ft) and 152.4 m (500 ft) sizes enable the efficient production of large series.

Depending on the pitch, pole numbers from 4 poles to 64 poles are available. The grey-colored strands with PVC sheathing have a red marking on pin 1. With a maximum operating voltage of 300 V and an extended temperature range of -20 °C to +105 °C, these cables are also suitable for use in electrically or thermally demanding applications.

An overview of all available versions and further technical information can be found in our online store.
